About Badminton Court Flooring
- BWF Grade 1 Approved Competition Flooring
- Non-Approved Training & Multi-Use Flooring
Both are constructed with:
- 100% PVC wear layer
- Reinforced fiberglass mesh
- Cushioned closed-cell foam backing
Available in 4.5 mm to 8.0 mm thickness, in roll-size 1.8 m × 15 m, with pre-marked lines and pattern options matching global standards.
Designed to deliver shock absorption, traction, uniform bounce, and visual appeal through cloth grain, gemstone, small stone, wood grain, or crystal-sand embossed surfaces.
Compatible with double sided tape (portable) or glue-down installations.
Badminton Court Flooring - Key Features
BWF Grade 1 Certified vs Non-Approved Training Option
Badminton Court Flooring - Technical Specifications
🔹 Approved (Competition Grade – BWF Grade 1 Certified)
| Attribute | Specification |
|---|---|
|
Total Thickness Wear Layer Thickness Roll Size Shock Absorption Slip Resistance Ball Bounce Vertical Deformation Installation Pattern Options Colours Certification Warranty |
4.5 mm or 6.5 mm 0.6–0.7 mm 1.8 m × 15 m ≥ 50% (measured per EN / BWF test protocols) R9–R11 (EN 13893) ≥ 90% ≤ 2.3 mm Glue-down or double-sided adhesive tape Cloth Grain, Wood Grain, Crystal Sand Green / Blue / Red (BWF standard) BWF Grade 1, EN 14904, CE, ISO 9001 / 14001 8–10 Years |
🔹 Non-Approved (Training / Multi-Use)
| Attribute | Specification |
|---|---|
|
Total Thickness Wear Layer Thickness Roll Size Shock Absorption Slip Resistance Ball Bounce Vertical Deformation Installation Pattern Options Colours Certification Warranty |
4.5 mm, 6 mm, 8 mm 0.5–0.7 mm 1.8 m × 15 m ≥ 45% R9–R11 ≥ 85–90% ≤ 2.5 mm Glue-down or adhesive tape Cloth Grain, Small Stone, Gemstone, Wood Grain Green, Blue, Red, Grey, Wood Tone, Custom Branding EN 14904, CE 5–8 Years |
Applications
International-level badminton tournaments (Approved)
Training academies, clubs, schools and universities (Non-Approved)
Multipurpose gym halls with portable layout
Why Gravolite?
📊 Performance Benchmarks
Meets or exceeds international standards for durability and playability.
🎨 Customized Branding
Line marking, logo embedding, and colour matching tailored for UAE & GCC academies.
⚡ Easy Installation
Quick setup with portable options and long-term warranties for peace of mind.
🏆 Competition-Ready
Engineered for both elite tournaments and everyday training environments.
FAQ'S
👉 The approved version achieves ≥ 50% shock absorption, vertical deformation ≤ 2.3 mm, and carries official BWF Grade 1 certification.
👉 Yes, the non-approved version can use double-sided tape for easy removal and reuse in community centers or events.
👉 It must be smooth, dry, clean and level. Any cracks or unevenness should be filled before installation.
👉 Options include cloth grain, gemstone, crystal-sand, small stone, wood grain, in green, blue, red, grey or custom branding colour.
👉 Simply wet or dry mop. The wear layer offers superior resistance to scuffs, stains and is hygienic.
Tailored To Your Needs-Size Thickness Color Customization Available.
High-Precision Manufacturing
Functional with Elegance
Industry-Recommended
Custom-Made Excellence
🚀 Let’s Build Your Badminton Court Flooring
Looking to install a BWF-approved tournament surface in Dubai, or set up a portable training court in a university hall in Abu Dhabi or Riyadh? Gravolite has you covered.
👉 Contact Gravolite UAE today to design your custom badminton court flooring solution!
