About SBR Gym Tiles
O
ur SBR Gym Tiles are engineered for high-performance flooring in gyms, fitness centers, and sports facilities.
Made from premium SBR recycled rubber crumb and bonded with advanced polymer technology,
these tiles deliver exceptional durability, shock absorption, and slip resistance.
They are ideal for heavy-duty use, offering superior protection for floors and equipment while enhancing
safety and comfort.
Key Features
Engineered with superior durability, safety, and flexibility for gyms and multi-sport environments.
Tech Specs – Classic SBR Gym Tiles
| Specification | 500×500 mm | 1000×1000 mm |
|---|---|---|
|
Type Thickness Weight per Tile Colors Material Composition Granule Size Technology Certifications Tensile Strength Elongation at Tear Density Specific Gravity Compression Set Temperature Resistance Abrasion Resistance Shore Hardness |
V-Groove 10 mm – 50 mm 2.5 kg – 12.5 kg* Black, Grey, Green, Terracotta, Blue SBR recycled rubber crumb with polymer bonding 0.8 mm – 2 mm Hot Molded IS: 3400, IS: 1237, ASTM D 792, ASTM D 1709, ASTM D 2240, STP/STC/BM02 1.7 MPa 1.2 990 kg/m³ 0.98 0.96% -40°C to +150°C 0.7% by weight 60–70 Shore A |
V-Groove 10 mm – 50 mm 10 kg – 50 kg* Black, Grey, Green, Terracotta, Blue Same as 500×500 mm 0.8 mm – 2 mm Hot Molded Same as 500×500 mm 1.7 MPa 1.2 990 kg/m³ 0.98 0.96% Same Same Same |
Tech Specs – Smooth SBR Gym Tiles
| Specification | 500×500 mm | 1000×1000 mm |
|---|---|---|
|
Type Thickness Weight per Tile Colors Material Composition Granule Size Technology Certifications Tensile Strength Elongation at Tear Density Specific Gravity Compression Set Temperature Resistance Abrasion Resistance Shore Hardness |
V-Groove 10 mm – 50 mm 2.5 kg – 12.5 kg* Black SBR recycled rubber powder with polymer bonding Fine SBR rubber powder Hot Molded IS: 3400, IS: 1237, ASTM D 792, ASTM D 1709, ASTM D 2240, STP/STC/BM02 1.5 MPa 1.2 980 kg/m³ 0.98 0.96% -40°C to +150°C 0.7% by weight 60–70 Shore A |
V-Groove 10 mm – 50 mm 10 kg – 50 kg* Black Same as 500×500 mm Fine SBR rubber powder Hot Molded Same as 500×500 mm 1.5 MPa 1.2 980 kg/m³ 0.98 0.96% Same Same Same |
Tech Specs – Sandwich SBR Tiles
| Specification | 500×500 mm | 1000×1000 mm |
|---|---|---|
|
Type Thickness Weight per Tile Colors Material Composition Granule Size Technology Certifications Tensile Strength Elongation at Tear Density Specific Gravity Compression Set Temperature Resistance Abrasion Resistance Shore Hardness |
Two-layer (wear layer + shock-absorbent base) 20 mm – 50 mm Top: 3–8 mm harder wear layer; Bottom: remainder softer core ~2.5 kg – 12.5 kg* (varies with thickness and layer density) Black, optional flecks / custom blends SBR recycled rubber (dual-density), polymerically bonded Textured / smooth wear layer for slip resistance High (engineered via softer base layer) – protects joints & equipment Significant dampening due to sandwich core design ~1.5–2.0 MPa (wear layer optimized for abrasion resistance) ~1.2 ~980–1000 kg/m³ (combined average, top layer slightly higher) ~0.98 ≤1% -40°C to +150°C Designed for heavy use; top layer wear-resistant (typical <1% weight loss) Top layer: 65–75 Shore A; Base: 55–65 Shore A (combined feel balanced) Loose-lay or interlocking / modular system (flat underside for stability) Meets typical gym flooring expectations (low VOCs, slip resistance, durability); can be tailored for regional compliance. |
Two-layer (wear layer + shock-absorbent base) 20 mm – 50 mm Same as 500×500 mm ~10 kg – 50 kg* Black, optional flecks / custom blends Same as 500×500 mm Same Same Same Same ~1.2 Same ~0.98 ≤1% Same Same Same Same Same |
Tech Specs – Hexagonal SBR Tiles
| Specification | 18″ × 18″ (457 × 457 mm) |
|---|---|
|
Shape Thickness Range Weight per Tile Colors Material Composition Surface Finish Shock Absorption Noise Reduction Tensile Strength Elongation at Tear Density Specific Gravity Compression Set Temperature Resistance Abrasion Resistance Shore Hardness Installation Certifications |
18″ × 18″ (Approx. 457 × 457 mm) Hexagon 10 mm – 20 mm ~2.2 kg – 4.5 kg* Black, Grey, Green, Blue, Terracotta SBR recycled rubber crumb, polymer bonded Textured slip-resistant High, protects joints and equipment Effective dampening for dropped weights ~1.5–1.7 MPa ~1.2 ~980–995 kg/m³ ~0.98 ≤1% -40°C to +150°C ≤0.7% weight loss ~60–70 Shore A Loose-lay or adhesive IS: 3400, IS: 1237, ASTM D 792, ASTM D 1709, ASTM D 2240 |
Why Choose Gravolite for SBR Gym Tiles?
FAQ'S
10–15 mm: Cardio zones, light fitness areas.
15–25 mm: Functional training, moderate weights.
25–50 mm: Weightlifting zones, CrossFit, high-impact areas.
Yes – our tiles are UV-stable, weather-resistant, and temperature-proof (-40°C to +150°C).
Yes – we offer multiple colors, fleck patterns, and logo printing.
Simple cleaning with a vacuum, broom, or damp mop; avoid harsh chemicals.
Yes – we offer on-site installation and layout services across GCC markets.
Tailored To Your Needs-Size Thickness Color Customization Available.
High-Precision Manufacturing
Functional with Elegance
Industry-Recommended
Custom-Made Excellence
Let’s Build Your Arena Together
Whether you’re designing a commercial gym, CrossFit box, personal training studio, or a multi-sport arena, Gravolite SBR Gym Tiles create a safe, high-performance environment that inspires athletes and protects your investment. Our team provides design consultation, layout planning, and after-sales support, ensuring your flooring not only looks professional but performs under the toughest conditions.
